E18S Series

The E18S series incremental rotary encoders are ultra-compact in size (Ø18 mm) and ultra-lightweight (12 g). The small size and light weight adds flexibility for application in tight or limited spaces. The low moment of inertia of the shaft minimizes the effect on the rotation of applied equipment. The miniature encoders are ideal for small machinery including ATMs, bill counters, copy machines, and other office machines.

Categories: ,


* Ultra-compact (Ø18 mm) and ultra-lightweight (12 g)
* Easy installation in tight or limited spaces
* Low moment of inertia
* Power supply: 5 VDC ±5%

Title Type Size
Rotary Encoders Selection Guide application/pdf 2 MB
E18S Series application/pdf 1 MB
Rotary Encoders (Applications) application/pdf 258 KB
Rotary Encoders (Technical Description) application/pdf 370 KB
Rotary Encoders (Product Overview) application/pdf 877 KB
E18S Series application/pdf 369 KB
